Cell parameters
| Type | LFP 315Ah |
| Cell configuration | 1P260S |
| Rated energy at DC side | 262kWh |
| Voltage range | 728V~923V |
System parameters
| Dimensions (W*D*H) | 950mm*1400mm*2120mm |
| Weight | 2400kg |
| Ingress protection rating | IP55 |
| Auxiliary power supply | External power supply |
| Anti-corrosion grade | C4-M |
| Operating ambient humidity | 0%~95% (non-condensing) |
| Operating ambient temperature | -20°C~55°C (derated when the operating temperature is over 45°C) |
| Max. operating altitude | 4000m (derated when the operating altitude is over 2000m) |
| Cooling method | Liquid-cooling |
| Fire protection | Aerosol + combustible gas detection + ventilation + water extinguishing system |
| Communication interface | LAN |
| Communication protoco | Modbus TCP |
Key Highlights
Adaptive To Harsh Environments
Resists extreme cold and heat
Intelligent internal dehumidification
prevents condensation
Modular Design For Easy
Construction
Allows parallel connection of multiple cabinets; Easy expansion and centralized control.
EMS generates optimal operation strategy;
Factory pre-commissioned; Plug and play on site
Good-Quality Cells
315Ah cells ensure superb safety and long life cycle
High energy efficiency (≥95%)
Small Size, Big Energy
High Energy Density （21% greater）
Compact footprint: 1.28 m²
Smart And User-Friendly
Smart and wireless; Supports remote upgrades
Related Cases
Kagoshima, Japan
2 MW / 6.7 MWh
Utilities
High-precision liquid cooling and integrated safety protocols ensure consistent performance and operational security in demanding utility-scale environments.
Balkan Peninsula
1.63 MW / 3.4 MWH
Manufacturing Facility
Built to resist corrosion and extreme temperatures (-20°C to 55°C), making it perfect for industrial operations.
